Engine Type: 4-stroke single, SOHC
Displacement: 233cc
Bore and Stroke: 67.0 x 66.0mm
Cooling: Air
Compression Ratio: 9.4:1
Fuel System: DFI® with 32mm Keihin throttle body
Ignition: TCBI Electronic Advance
Front Suspension: 37mm telescopic fork/8.7 in. travel
Front Brakes: Single 240mm petal disc with a dual-piston caliper
Front Tire: 80/100-21
Rear Suspension: Uni-Trak® linkage system and single shock with adjustable spring preload/8.8 in. travel
Rear Brakes: Single 220mm petal disc with single-piston caliper
Rear Tire: 100/100-18
Dry Weight: Curb Weight: 253.6 lb. / 262.3 lb. CA model
Fuel Capacity: 1.7 gal.
Wheelbase: 53.1 in.
Ground Clearance: 10.8 in.
Seat Height: 35.4 in.
Trail: 4.3 in.
Rake: 25.7 deg.
Transmission: 6-speed, return shift with wet multi-disc manual clutch
Final Drive: Chain
Colors: Lime Green
