Engine Type: OHV longitudinally mounted single-cylinder four-stroke
Displacement: 229cc
Bore x Stroke: 68.5mm x 62.2mm
Cylinders: 1
Engine Cooling: Air
Fuel System: 22mm carburetor
Starting System: Electric with optional auxiliary recoil
Front Suspension: Independent double-wishbone
Front Travel: 5.1 in.
Front Brake Type: Dual sealed hydraulic drum
Front Tires: 22 x 7-11
Rear Travel: 4.9 in.
Rear Suspension: Swingarm with single shock
Rear Brake Type: Sealed mechanical drum
Rear Tires: 22 x 10-9
Dry Weight: Curb Weight: 437 lb.
Front Rack Capacity: 33 lb.
Rear Rack Capacity: 66 lb.
Fuel Capacity: 2.4 gal., including 0.6-gal. reserve
Ground Clearance: 6.0 in.
Machine Dimensions (LxWxH): 75.0 in. x 40.7 in. x 42.1 in.
Wheelbase: 44.5 in.
Final Drive: Direct rear driveshaft
Transmission: Five-speed manual with reverse
Colors: Red, Moose Brown, Zest Orange
