Engine Type: Single-cylinder four-stroke
Displacement: 518cc
Bore x Stroke: 96.0mm x 71.5mm
Cylinders: 1
Engine Cooling: Liquid
Fuel System: Programmed Fuel Injection (PGM-FI); 36mm throttle body
Starting System: Electric with optional auxiliary recoil
Front Suspension: Independent double-wishbone
Front Travel: 7.3-in.
Front Brake Type: Dual 190mm discs
Front Tires: 25 x 8-12
Rear Suspension: Independent dual-arm
Rear Travel: 8.5-in.
Rear Brake Type: Dual 170mm discs
Rear Tires: 25 x 10-12
Dry Weight: Curb Weight: 719 lb.
Front Rack Capacity: 99 lb.
Rear Rack Capacity: 187 lb.
Towing Capacity: 1322 lb.
Fuel Capacity: 3.9 gal., including 1.3-gal. reserve
Ground Clearance: 9.7 in.
Machine Dimensions (LxWxH): 86.0 in. x 47.4 in. x 48.7 in.
Wheelbase: 50.9 in.
Final Drive: Direct front and rear driveshafts with TraxLok® and locking front differential
Transmission: Five-speed automatic dual-clutch transmission with reverse and Low/Drive sub-transmission
Colors: Matte Gray Metallic, Matte Navy Blue
