Engine Manufacturer: Kubota
Engine Type: Direct Injection, Vertical, Water-Cooled 4 Cycle Diesel
Horsepower: 33.0 HP (24.6 kW)
PTO HP: 26.1 HP (19.5 kW)
Rated RPM: 2700 RPM
Bore and Stroke: 3.4 x 4.0 in. (87 x 102.4 mm)
Wheelbase: 63.4 in. (1610 mm)
Height: W/ Foldable ROPS: 91.7 in. (2330 mm)
Width: min. tread: 55.1 in. (1400 mm)
Weight: W/ROPS: 2899 lb. (1315 kg.)
Ground Clearance: 13.4 in. (340 mm)
Tire Size: AG Standard - Front: 7.0 - 16; Rear: 11.2 - 24; TURF Option - Front: 25 x 8.50 - 14; Rear: 13.6 - 16; Industrial Option - Front: 27 x 8.50 - 15; Rear: 15 - 19.5 R4; AG/Indust. Hybrid Option - Front: 27 x 8.50 - 15 R14; Rear: 15 - 19.5 R4
Fuel System: Direct Injection
Fuel Capacity: 11.1 gal. (42 L)
Transmission: Hydrostatic transmission, 3 range speed
Brakes: Mechanical, Wet Disc Type
Hydraulics: Pump Capacity (Main): 6.8 gpm. (25.7 l/min.); Pump Capacity (PS): 4.1 gpm. (15.6 l/min.)
Drive Type: 4WD
