Engine Type: V Twin
Displacement: 47.8 cu. in. (783 cc)
Bore and Stroke: Bore: 3.35 in. (85 mm); Stroke: 2.72 in. (69 mm)
Cooling: Liquid
Compression Ratio: 10.7:1
Fuel System: Gas
Front Suspension: Double A-Arm
Front Brakes: Dual Hydraulic Disc
Front Tire: Maxxis® 26 x 9-12
Rear Suspension: Independent
Rear Brakes: Sealed Oil Bath Multi-Disc
Rear Tire: Maxxis® 26 x 11-12
Wheelbase: 85.8 in. (2179.3 mm)
Front Travel: 8 in. (203.2 mm)
Rear Travel: 8.3 in. (210.8 mm)
Ground Clearance: 11.2 in. (284.5 mm)
Fuel Capacity: 7.9 gal. (29.9 L)
Box Capacity: 600 lbs. (272.2 kg.)
Towing Capacity: 1300 lb. (589.7 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Odometer: Standard
