Engine Manufacturer: Kubota
Engine Type: Vertical, water-cooled, 4 -cycle diesel with turbo chager
Horsepower: 34.9 HP (26.0 kW)
PTO HP: 28.7 HP (21.4 kW)
Rated RPM: 2700 RPM
Bore and Stroke: 3.1 × 3.1 in. (78 × 78.4 mm)
Wheelbase: 66.7 in. (1695 mm)
Height: 85.6 in. (2175 mm)
Width: 53.7 in. (1365 mm)
Weight: 2624 lb. (1190 kg)
Ground Clearance: 8.9 in. (225 mm)
Tire Size: Front (R1): 7-12, Front (R4): 23 x 8.50-14, Front (R14): 23 x 8.50-12; Rear (R1): 12.4 - 16, Rear (R4): 12.4 - 16, Rear (R14): 14 - 17.5
Fuel System: Direct injection
Fuel Capacity: 8.5 gal. (32.0 L)
Transmission: HST (3 ranges)
Brakes: Front drive disengaged
Hydraulics: Total Hydraulic Flow: 9.5 gpm (35.8 l/min)
Drive Type: 4WD
