Engine Type: Single-Cylinder
Displacement: 2.9 cu. in. (46.9 cc)
Bore and Stroke: Bore: 1.56 in. (39.5 mm); Stroke: 1.6 in. (40.7 mm)
Cooling: Liquid
Fuel System: Gas / Oil Premix
Front Suspension: Inverted Fork
Front Brakes: Hydraulic Disc
Front Tire: Maxxis® Maxxcross MX-ST: 60/100 - 12 (36J)
Rear Suspension: Twin Sided Swing Arm
Rear Brakes: Hydraulic Disc
Rear Tire: Maxxis® Maxxcross MX-ST: 2.75 x 10 (38J)
Dry Weight: 93.7 lb. (42.5 kg.)
Fuel Capacity: 0.6 gal. (2.3 L)
Wheelbase: 40.4 in. (1026 mm)
Ground Clearance: 9.2 in. (233 mm)
Seat Height: 25.4 in. (645 mm)
Rake: 24
Transmission: Automatic
Final Drive: 3.64
