Engine Type: Four-stroke single with DOHC and four-valve cylinder head
Displacement: 249cc
Bore and Stroke: 77.0 x 53.6mm
Cooling: Liquid
Compression Ratio: 13.8:1
Fuel System: DFI® with 43mm Keihin throttle body and dual injectors
Ignition: Digital DC-CDI
Front Suspension: 48mm inverted Showa SFF telescopic fork with 40-way spring preload adjustability and 22-position compression and 20-position rebound damping adjustability
Front Brakes: Single semi-floating 270mm petal disc with dual-piston caliper
Front Tire: 80/100-21
Rear Suspension: Uni-Trak® linkage system and Showa shock with 19-position low-speed and 4-turns high-speed compression damping, 22-position rebound damping, fully adjustable spring preload
Rear Brakes: Single 240mm petal disc with single-piston caliper
Rear Tire: 100/90-19
Dry Weight: Curb Weight: 233.7 lb.
Fuel Capacity: 1.61 gal.
Wheelbase: 58.1 in.
Ground Clearance: 13 in.
Seat Height: 37.2 in.
Trail: 5 in.
Rake: 28.7 deg.
Transmission: Five-speed with wet multi-disc manual clutch
Final Drive: Chain
Colors: Lime Green
