Engine Type: Parallel Twin
Displacement: 60.9 cu. in. (999 cc)
Bore and Stroke: Bore: 3.66 in. (93 mm); Stroke: 2.89 in. (73.5 mm)
Cooling: Liquid
Compression Ratio: 10.5:1
Fuel System: Gas
Front Suspension: Independent Double A-Arm
Front Brakes: Hydraulic Disc
Front Tire: Pro Armor® Crawler XGF: 30 x 10-15
Rear Suspension: Independent
Rear Brakes: Hydraulic Disc
Rear Tire: Pro Armor® Crawler XGF: 30 x 10-15
Dry Weight: 1654 lb. (750 kg.)
Wheelbase: 83 in. (2110 mm)
Front Travel: 14 in. (356 mm)
Rear Travel: 14 in. (356 mm)
Ground Clearance: 13.5 in. (343 mm)
Fuel Capacity: 9.5 gal. (35.9 L)
Box Capacity: 600 lbs. (272 kg.)
Towing Capacity: 1500 lb. (680.4 kg.)
Drive System: Continuously Variable (CVT)
Speedometer: Standard
Tachometer: Standard
Odometer: Standard
