Engine Type: 2-stroke, liquid-cooled, reed-valve, single
Displacement: 249 cc
Bore and Stroke: 66.4 x 72 mm
Compression Ratio: 7.9 ~ 9.4:1
Fuel System: Keihin PWK38S
Front Suspension: Fully adjustable 48 mm inverted fork / 300 mm (11.8 in.) travel
Front Brakes: 270 mm floating disc / twin piston caliper
Front Tire: 80/100-21
Rear Suspension: Fully adjustable link Monocross / 315 mm (12.4 in.) travel
Rear Brakes: 240 mm disc / single piston caliper
Rear Tire: 110/100-18
Fuel Capacity: 8 L (1.8 imp. gal.)
Wheelbase: 1,485 mm (58.5 in.)
Ground Clearance: 360 mm (14.2 in.)
Seat Height: 975 mm (38.4 in.)
Transmission: Constant mesh, 5-speed
Final Drive: Chain
Colors: Yamaha Racing Blue
