Engine Type: Single-Cylinder
Displacement: 12 cu. in. (196 cc)
Bore x Stroke: Bore: 2.56 in. (65 mm); Stroke: 2.32 in. (59 mm)
Cylinders: 1
Engine Cooling: Air
Fuel System: Gas
Starting System: Electric
Front Suspension: Double A-Arm
Front Travel: 7 in. (178 mm)
Front Brake Type: Hydraulic Disc
Front Tires: Duro: 21 x 7-10
Rear Suspension: Swing Arm
Rear Travel: 6.5 in. (165 mm)
Rear Brake Type: Drum
Rear Tires: Duro: 20 x 10-9
Frame: Steel
Dry Weight: 420 lb. (191 kg.)
Towing Capacity: 300 lb. (136.1 kg.)
Fuel Capacity: 2.5 gal. (9.5 L)
Ground Clearance: 5.7 in. (145 mm)
Machine Dimensions (LxWxH): L: 65 in. (1651 mm); W: 42 in. (1067 mm); H: 42 in. (1067 mm)
Wheelbase: 45 in. (1143 mm)
Drive Train: Continuously Variable (CVT)
