Engine Type: 2-stroke single with exhaust power valve (KIPS)
Displacement: 112cc
Bore and Stroke: 52.5 x 51.6mm
Cooling: Liquid
Compression Ratio: 9.9:1 (Low speed)/8.6:1 (High speed)
Fuel System: 28mm Keihin Carburetor
Ignition: CDI with digital advance
Front Suspension: 36mm inverted telescopic cartridge fork with 20-way compression damping/10.8 in. travel
Front Brakes: Single 220mm petal disc with dual-piston caliper
Front Tire: 70/100-19
Rear Suspension: Uni-Trak® gas charged shock with piggyback reservoir with 24-way compression and 21-way rebound damping plus adjustable spring preload/10.8 in. travel
Rear Brakes: Single 184mm petal disc with single-piston caliper
Rear Tire: 90/100-16
Dry Weight: Curb Weight: 169.7 lb.
Fuel Capacity: 1.32 gal.
Wheelbase: 51.6 in.
Ground Clearance: 13.0 in.
Seat Height: 34.3 in.
Trail: 4.3 in.
Rake: 29 deg.
Transmission: 6-speed, return shift, with wet multi-disc manual clutch
Final Drive: Chain
Colors: Lime Green
