Engine Type: Testastretta 11°, L-Twin, 4 Desmodromically actuated valves per cylinder
Displacement: 821 cc (50.1 cu in.)
Bore and Stroke: 3.46 x 2.66 in. (88 x 67.5 mm)
Cooling: Liquid
Compression Ratio: 12.8:1
Fuel System: Electronic fuel injection system, Ø 53 mm throttle bodies, Full Ride-by-Wire
Transmission: 6 speed
Final Drive: Chain drive, Front sprocket Z15, Rear sprocket Z46
Front Suspension: Ø 43 mm usd fork
Rear Suspension: Progressive linkage with adjustable monoshock, Aluminium double-sided swingarm
Front Brakes: 2 x Ø 320 mm semi-floating discs, radially mounted monobloc Brembo M4-32 callipers, 4-piston, axial pump with Bosch ABS 9.1 MP as standard equipment
Rear Brakes: Ø 245 mm disc, 2-piston calliper with Bosch ABS 9.1 MP as standard equipment
Front Tire: 120/70 ZR 17 Pirelli Diablo Rosso III
Rear Tire: 180/55 ZR17 Pirelli Diablo Rosso III
Wheelbase: 58.27 in. (1,480 mm)
Seat Height: 30.91 in. - 31.89 in. (785 mm - 810 mm)
Rake: 24.3 deg.
Trail: 3.67 in. (93.2 mm)
Fuel Capacity: 4.36 US gal. (16.5 L)
Dry Weight: 398 lb. (180.5 kg)
Colors: Ducati Red
